4 Ton Wheel Loader
ZT946
Features
Enhanced Operator Comfort Cabin
ZT946 is equipped with optional air conditioning, heater, ergonomic seat, and optimized cabin layout, providing a more comfortable working environment for operators during long-hour operations in construction and material handling sites.
Global Engine Compliance System
The 4-ton wheel loader offers multiple engine options including Weichai , Cummins, and Fiat engines with Euro V, EPA, and Brazil certification options. This ensures compliance with different regional emission standards and enables the machine to be used in global markets.
OEM-Level Hydraulic & Component System
Key hydraulic components including pumps, valves, and cylinders are sourced from suppliers that also serve global brands such as John Deere, JCB, XCMG, LOVOL, and Shantui, ensuring industrial-grade reliability and stable performance.
Multi-Function Working Capability
ZT946 supports a wide range of optional attachments including bucket upgrades, fork systems, grapples, augers, breaker hammers, and snow blades, enabling one machine to perform multiple tasks such as loading, lifting, grabbing, and material handling.
Precision Control System
The machine offers both mechanical and pilot control valve options, including three-way and four-way hydraulic systems, enabling smoother operation response, higher precision, and better adaptability for different working conditions.
Specifications
| Rated Load | kg | 4000 |
| Bucket Width | mm | 2500 |
| Bucket Capacity | m³ | 2 |
| Overall Dimension | mm | 7230*2520*3250 |
| Operating Weight | kg | 11000 |
| Max. Dumping Height | mm | 3200 |
| Max. Dumping Distance | mm | 1100 |
| Wheel Base | mm | 2750 |
| Wheel Tread | mm | 1850 |
| Engine | WeiChai | |
| Rated Power | kw | 129 |
| Rated Speed | r/min | 2200 |
| Tire Size | 20.5-25 |
Product Showcase
Why Choose TDER?
20+ Years of Expertise
158 Countries Served
42,000㎡ of Advanced Production
Over $91M+ Annual Sales
