380kg Skid Steer Loader
TDS30
Features
Solid Tire & Narrow Track Design for Stable Ground Contact
Standard 6.5-10 solid tires provide stronger puncture resistance and stability, while the narrow wheelbase design ensures safe movement in tight passages and uneven working surfaces.
Hydraulic Pilot Control Upgrade for Easier Operation & Higher Precision
Compared with mechanical control, the hydraulic pilot system reduces operating effort and provides smoother, more precise movement control, making the machine easier to handle during frequent loading, lifting, and maneuvering tasks. It also improves response consistency across multiple functions, helping operators maintain better control in continuous working conditions.
Global Emission Compliance Engine
The Kubota D1105 18.2kW engine is designed to meet EPA Tier 4 and Euro V emission standards, ensuring compliance with strict environmental regulations across different global markets.
Stable Hydraulic Power Delivery Under Load
The Italian PWG pump and HB valve system provides stable hydraulic power and consistent force during heavy-load and multi-action operations, reducing performance fluctuation and improving overall working reliability in daily job site use.
Operator Comfort Upgrade Options for All-Weather Working
TDS30 supports upgrading from an open cab to a fully enclosed cabin with optional heater, improving comfort and usability in cold or harsh weather conditions. An optional air-suspension deluxe seat is also available, helping reduce vibration impact during long working hours and enhancing overall operator comfort and fatigue resistance.
Specifications
| Operating Load | Kg | 380 |
| Max Speed | Km/H | 9 |
| Rated Flux | L/Min | 50 |
| High Flow Flux | L/Min | / |
| Tire Model | 6.50-10 | |
| Self Weight Bucket | Kg | 1300 |
| Bucket Capacity | M³ | 0.2 |
| Overall Operating Height | mm | 3400 |
| Hheight To Top Of Cab | mm | 1813 |
| Without Bucket Length | mm | 2200 |
| Overall Length With Bucket | mm | 2950 |
| Dumping Height | mm | 2000 |
| Width | mm | 920 |
| Bucket Width | mm | 1070 |
| Height To Bottom Of Level Bucket | mm | 2446 |
| Dumping Angle At Maximum Height | ° | 40 |
| Height To Bucket Hinge Pin | mm | 2500 |
| Dumping Reach | mm | 441 |
| Rollback Of Bucket On Ground | ° | 30 |
| Rollback Of Bucket At Full Height | ° | 103 |
| Wheelbase | mm | 801 |
| Ground Clearance | mm | 145 |
| Angle Of Departure | ° | 20 |
| Front Turning Radius Without Bucket | mm | 960 |
| Front Tuning Radius | mm | 1660 |
| Rear Tuning Radius | mm | 1253 |
| Rear Axle To Bumper | mm | 910 |
| Tread Width | mm | 785 |
| Engine | Kubota D1105 | |
| Rated Power | Kw | 18.2 |
| Fuel Tank Capacity | L | 28 |
