Features

High-Power Electric Drive Excavation System

The 55kW 380V high-voltage electric drive system delivers stable and continuous high-torque output, ensuring reliable performance in heavy-duty excavation, mining, and earthmoving operations. Compared with diesel-powered systems, it reduces energy consumption by up to 70% while maintaining strong productivity under continuous load conditions.

Industrial-Grade Hydraulic Transmission System

Equipped with Zhongchuan main pump, control valve, travel motor, and swing motor system, the hydraulic architecture ensures stable pressure output and precise operation control. The integrated system is designed for heavy-load excavation environments, delivering consistent performance in mining and large-scale construction applications.

Zero-Emission Low-Noise Operating Platform

The electric power system enables zero emissions and significantly reduced operational noise, making the machine suitable for environmentally restricted zones, underground construction, and urban infrastructure projects where emission control is required.

Low Maintenance Electric Powertrain System

The electric drive system eliminates traditional engine maintenance requirements. Key components such as the motor only require lubrication every 2000 hours, significantly reducing downtime and long-term maintenance costs while improving overall equipment availability.

Multi-Scenario Working Capability System

Through quick attachment replacement, the machine can adapt to multiple working conditions including excavation, loading, and material handling, providing high versatility for mining, construction, and infrastructure projects.

High-Safety Electrical Control Architecture

The electric control system is equipped with 4-pole leakage protection, centralized circuit transfer station, and CMC-MX soft-start technology, ensuring safe power distribution, reduced starting current, and improved system reliability under complex jobsite conditions.

Operator Comfort and High-Stability Cabin System

The ROPS-certified cabin features panoramic visibility, air-conditioning, ergonomic controls, and reinforced steel structure, ensuring operator safety and reduced fatigue during long-duration heavy-duty operations.

Specifications

Total weight	kg	21500
Bucket capacity	M³	0.9-1.2
Motor model		YE3-250M-4
Rated power	Kw/r/min	55/1480
Rated voltage	V	380
Rated stored energy	KWh	/
Max displacement	L/min	210*2
Working pressure	Mpa	34.3
Hydraulic pump mode		APVO125
Hydraulic tank volume	L	230
Walking speed (high/low)	km/h	4.5/2.5
Swing speed	r/min	8.7
Climbing ability	°	35
Bucket excavation force	KN	147.9
Arm digging force	KN	107.3
Ground specific voltage	KPa	50.8
Traction force	KN	223
Max. excavation height	mm	9270
Max. unloading heigh	mm	6600
Max.excavation depth	mm	6525
Max. verticalarm mining depth	mm	5670
The distance when digging 2.5 horizontal plane	mm	6327
Max. excavation distance	mm	9820
Max. excavation distance on the ground	mm	9630
Min. turning radius	mm	3800
Max. height at minimum turning radius	mm	7640
Distance from the center of rotation to the rear end	mm	2800
Counterweight height	mm	2120
Grounding length during transportation	mm	4970
Overalllength	mm	9535
Overall width	mm	2780
Total heigh(boom top)	mm	3140
verall height(top ofcab)	mm	3090
Counterweight ground clearance	mm	1080
Min. ground clearance	mm	470
Tail turning radius	mm	2800
Track grounding length	mm	3260
Track length	mm	4070
Rail guage	mm	2180
Track width	mm	2780
Track shoe width	mm	600
Turntable width	mm	2700
rack tooth thickness	mm	26
Arm length	mm	2900
Boom length	mm	5700

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
