Name: 10 Ton Large Wheel Loader with Cummins Engine and ZF Powertrain
Availability: InStock

Features
Specifications
Product Showcase
Gallery
FAQs
Related Products

Features

ZF Full Powertrain & Wet Axle System for Premium Heavy-Duty Performance

ZT1000 is equipped with a full ZF powertrain system, including the ZF 4WG310 transmission and ZF wet axle system, delivering smooth power transfer, fast response, and high-efficiency operation under continuous heavy-duty working conditions.

The electro-hydraulic proportional shifting technology ensures precise gear changes and improved driving comfort, while the ZF wet axle enhances heat resistance, load capacity, and long-term durability, making the machine suitable for high-intensity and continuous operation environments.

Global Premium Engine Platform by Cummins

Powered by a Cummins 264kW turbocharged intercooled engine (6LTAA8.9-C360), ZT1000 delivers strong torque output and stable performance under extreme working conditions. As a globally recognized engine brand, Cummins ensures reliability, fuel efficiency, and long service life.

Danfoss & Rexroth Hydraulic System for Stable Output

Equipped with Danfoss pump and valve system and Rexroth hydraulic components, ZT1000 ensures precise flow control, stable hydraulic response, and high efficiency in continuous heavy-load operations.

Maximum Material Output with 6m³ Ultra-Large Bucket System

ZT1000 is equipped with a 6m³ reinforced bucket and high breakout force of 270kN, enabling extremely high material handling capacity per cycle. This significantly improves loading efficiency in bulk material environments such as mining sites, ports, and large-scale aggregates yards

Intelligent Control System for Precise Operation

The fingertip control system enables highly precise hydraulic operation with minimal effort, improving responsiveness and reducing operator fatigue. This system enhances efficiency in repetitive loading cycles and allows smoother machine control.

Luxury Operator Cabin for Long-Hour Productivity

The fully equipped cabin with air conditioning, ergonomic design, and noise reduction structure ensures a comfortable working environment, helping operators maintain high productivity during long shifts.

Specifications

Performance	Rated Load Capacity	kg	10000
	Operating Weight	kg	31600
	Bucket Capacity Range	m³	4.0 - 9.0
	Overall Length	mm	9790
	Overall Height (H)	mm	3785
	Overall Width (W - Bucket Exterior)	mm	3532
	Dumping Height (B)	mm	3330
	Dumping Reach (C)	mm	1430
	Max. Digging Depth (D)	mm	127
	Full Turn Tipping Load	kg	20400
	Max. Breakout Force	kN	270
	Min. Ground Clearance	mm	442
	Wheelbase (G)	mm	3700
	Wheel Track	mm	2420
Engine	Model		Cummins 6LTAA8.9-C360
	Displacement	L	8.9
	Rated Power	kW	264
Transmission	Model		ZF 4WG310
	Type		Countershaft Powershift
	Gears		4 Forward / 3 Reverse
Hydraulic System	Working System		Variable dual-pump confluence
	Control Type		Fingertip control +1
	Steering System		Load-sensing hydraulic steering
Drive Axle			ZF Wet-type Axle
Tires			29.5-25 Pr28
Brake System			Full hydraulic wet-type braking
A/C System			Heating and Cooling

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

Gallery

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
